rotary encoder, also called a shaft encoder, is an electro-mechanical device that converts the angular position or motion of a shaft or axle to analog or digital output signals.

Rotary encoders are used in a wide range of applications that require monitoring or control, or both, of mechanical systems, including industrial controls, robotics, photographic lenses, computer input devices such as optomechanical mice and trackballs, controlled stress rheometers, and rotating radar platforms.

You can buy as module or only the encoder

Rotative encoders photo
Rotative encoders

You can find here

Rotative encoder module photo
Rotative encoder module

You can find here

Rotary encoder with switch pinout
Rotary encoder with switch pinout

Module is more simple to manage, the most tedious problem of a rotary encoder is the noise generated. Module have only a simple pull-up resistor to reduce noise, but if you want use the encoder in native format you must apply a pull-up resistor and a simple filter.

Encoder module schema
Encoder module schema

For pull-UP I use a 10k resistor connected to the VCC, for the filter I use a 10k resistor from encoderPin and a 100nF capacitor connected to the GND.

Encoder filter schema
Encoder filter schema

The encoder work with the rotation of plate that connect switch.

The movement generate a predeterminated sequence:

Incremental directional encoder
Incremental directional encoder

So we must decode this sequence to get rotation versus and movement.

Library

You can find my library here.

To download.

Click the DOWNLOADS button in the top right corner, rename the uncompressed folder PCF8574.

Check that the PCF8574 folder contains PCF8574.cpp and PCF8574.h.

Place the PCF8574 library folder your /libraries/ folder.

You may need to create the libraries subfolder if its your first library.

Restart the IDE.

IC or Module

You can use a normal IC or module.

pcf8574 IC

You can find here

pcf8574 module

You can find here

Connection schema

As we explain to connect an encoder to pcf8574 or directly to microcontroller you need a filter to reduce noise, or you must use a module.

Here a complete connection schema on breadboard.

WeMos D1 mini (esp8266) pcf8574 encored breadboard schema
WeMos D1 mini (esp8266) pcf8574 encored breadboard schema

That result in this photo.

Rotative encoders breadboard
Rotative encoders breadboard

Basic usage

Here a basic sketch that use a basic features of my library.

/*
 * PCF8574 GPIO Port Expand
 * https://www.mischianti.org
 *
 * PCF8574    ----- WeMos
 * A0         ----- GRD
 * A1         ----- GRD
 * A2         ----- GRD
 * VSS        ----- GRD
 * VDD        ----- 5V/3.3V
 * SDA        ----- D1(PullUp)
 * SCL        ----- D2(PullUp)
 * INT        ----- INT(PullUp)
 *
 * P0     ----------------- ENCODER PIN A
 * P1     ----------------- ENCODER PIN B
 * P2     ----------------- ENCODER BUTTON
 *
 */
#include "Arduino.h"
#include "PCF8574.h"

int encoderPinA = P0;
int encoderPinB = P1;

#define INTERRUPTED_PIN D7

void ICACHE_RAM_ATTR updateEncoder();

// initialize library
PCF8574 pcf8574(0x38, INTERRUPTED_PIN, updateEncoder);

volatile long encoderValue = 0;
uint8_t encoderButtonVal = HIGH;

void setup()
{
	  Serial.begin (9600);
	  delay(500);

	  // encoder pins
	  pcf8574.pinMode(encoderPinA, INPUT_PULLUP);
	  pcf8574.pinMode(encoderPinB, INPUT_PULLUP);
	  // encoder button
	  pcf8574.pinMode(P2, INPUT_PULLUP);

	  // Set low latency with this method or uncomment LOW_LATENCY define in the library
	  // Needed for encoder
//	  pcf8574.setLatency(0);

	  // Start library
	  pcf8574.begin();
}

bool changed = false;

void loop()
{
	if (changed){
		Serial.print("ENCODER --> ");
		Serial.print(encoderValue);
		Serial.print(" - BUTTON --> ");
		Serial.println(encoderButtonVal?"HIGH":"LOW");
		changed = false;
	}
}

uint8_t encoderPinALast = LOW;
uint8_t valPrecEncoderButton = LOW;

void updateEncoder(){
	// Encoder management
	uint8_t n = pcf8574.digitalRead(encoderPinA, true);
	if ((encoderPinALast == LOW) && (n == HIGH)) {
		if (pcf8574.digitalRead(encoderPinB, true) == LOW) {
			encoderValue--;
			changed = true; // Chnged the value
		} else {
			encoderValue++;
			changed = true; // Chnged the value
		}
	}
	encoderPinALast = n;

	// Button management
	encoderButtonVal = pcf8574.digitalRead(P2);
	if (encoderButtonVal!=valPrecEncoderButton){
	  changed = true; // Chnged the value of button
	  valPrecEncoderButton = encoderButtonVal;
	}
}

There are some important thing to denote:

In the esp8266 to create a callback for the interrupt you must specify ICACHE_RAM_ATTR.

void ICACHE_RAM_ATTR updateEncoder();

Encoder pins is INPUT_PULLUP

	  // encoder pins
	  pcf8574.pinMode(encoderPinA, INPUT_PULLUP);
	  pcf8574.pinMode(encoderPinB, INPUT_PULLUP);

You must set low latency to the pcf8574 and there are 2 ways:

  • use pcf8574.setLatency(0); command that set to 0 the latency;
  • remove comment on // #define PCF8574_LOW_LATENCY;
  • or better only for encoder use pcf8574.digitalRead(encoderPinA, true) with additional parameter at true;

Now, we have a lot of false read and duplicate read (interrupt is generated for every veriation), even if we have set the filter.

So in the procedure we are going to check when the value is effective changed, and controlled by changed variable.

Library features usage

Library get a set of method to do all operation in a trasparent mode.

Instead of use of pinMode you can use directly encoder like so.

PCF8574::encoder(uint8_t pinA, uint8_t pinB)

so the declaration become:

	// encoder pins
	pcf8574.encoder(encoderPinA, encoderPinB);

and all logic of encoder have 2 new manager, the first return the movement, like -1, 0 or 1.

int8_t PCF8574::readEncoderValue(uint8_t pinA, uint8_t pinB)

than the previous logic become

	int vale = pcf8574.readEncoderValue(encoderPinA, encoderPinB);
	if (vale!=0){
		changed = true;
	}
	encoderValue = encoderValue + vale;

another more pratival method is this:

bool PCF8574::readEncoderValue(uint8_t pinA, uint8_t pinB, volatile long *encoderValue)

that return if encoder have change is value (-1 or +1) and when you pass the reference of encoderValue the method update the external value.

So the code become:

changed = pcf8574.readEncoderValue(encoderPinA, encoderPinB, &encoderValue);

Here the previous sketch become

/*
 * PCF8574 GPIO Port Expand
 * https://www.mischianti.org
 *
 * PCF8574    ----- WeMos
 * A0         ----- GRD
 * A1         ----- GRD
 * A2         ----- GRD
 * VSS        ----- GRD
 * VDD        ----- 5V/3.3V
 * SDA        ----- D1(PullUp)
 * SCL        ----- D2(PullUp)
 * INT        ----- INT(PullUp)
 *
 * P0     ----------------- ENCODER PIN A
 * P1     ----------------- ENCODER PIN B
 * P2     ----------------- ENCODER BUTTON
 *
 */
#include "Arduino.h"
#include "PCF8574.h"

int encoderPinA = P0;
int encoderPinB = P1;

#define INTERRUPTED_PIN D7

void ICACHE_RAM_ATTR updateEncoder();

// initialize library
PCF8574 pcf8574(0x38, INTERRUPTED_PIN, updateEncoder);

volatile long encoderValue = 0;
uint8_t encoderButtonVal = HIGH;

void setup()
{
	Serial.begin (9600);
	delay(500);

	// encoder pins
	pcf8574.encoder(encoderPinA, encoderPinB);
	// encoder button
	pcf8574.pinMode(P2, INPUT_PULLUP);

	// Start library
	pcf8574.begin();

}

bool changed = false;

// The loop function is called in an endless loop
void loop()
{
	if (changed){
		Serial.print("ENCODER --> ");
		Serial.print(encoderValue);
		Serial.print(" - BUTTON --> ");
		Serial.println(encoderButtonVal?"HIGH":"LOW");
		changed = false;
	}
}

bool valPrec = LOW;
void updateEncoder(){
	changed = pcf8574.readEncoderValue(encoderPinA, encoderPinB, &encoderValue);

//	int vale = pcf8574.readEncoderValue(encoderPinA, encoderPinB);
//	if (vale!=0){
//		changed = true;
//	}
//	encoderValue = encoderValue + vale;

	bool val = pcf8574.digitalRead(P2);
	if (val!=valPrec){
	  changed = true;
	  valPrec = val;
	}
}

Thanks
