DOIT ESP32 DEV KIT v1: high resolution pinout and specs

Spread the love

ESP32 DOIT DEV KIT v1 pinout
ESP32 DOIT DEV KIT v1 pinout

Link to the high resolution pinout image

The DoIt ESP32 DevKit V1 is a development board that features the ESP32 microcontroller from Espressif. It is designed for IoT (Internet of Things) projects and applications.

You can find It here ESP32 Dev Kit v1 - TTGO T-Display 1.14 ESP32 - NodeMCU V3 V2 ESP8266 Lolin32 - NodeMCU ESP-32S - WeMos Lolin32 - WeMos Lolin32 mini - ESP32-CAM programmer - ESP32-CAM bundle - ESP32-WROOM-32 - ESP32-S

The board includes Wi-Fi and Bluetooth capabilities, a variety of input/output interfaces including GPIO, analog inputs, UART, SPI, and I2C. It also has a standard form factor that makes it easy to embed in projects and a USB port for power and programming. The ESP32 DevKit V1 is popular among hobbyists and educators for its ease of use and versatility in various electronic projects.

Specifications

  • Processors:
    • CPU: Xtensa dual-core (or single-core) 32-bit LX6 microprocessor, operating at 160 or 240 MHz and performing at up to 600 DMIPS
    • Ultra low power (ULP) co-processor
  • Memory: 520 KiB SRAM
  • Wireless connectivity:
    • Wi-Fi: 802.11 b/g/n
    • Bluetooth: v4.2 BR/EDR and BLE (shares the radio with Wi-Fi)
  • Peripheral interfaces:
  • Security:
  • Power management:
    • Internal low-dropout regulator
    • Individual power domain for RTC
    • 5μA deep sleep current
    • Wake up from GPIO interrupt, timer, ADC measurements, capacitive touch sensor interrupt

Pinout description

The DoIt ESP32 DevKit V1 features a comprehensive pinout that caters to a wide range of functionalities. Here’s a brief overview of its pinout:

  1. GPIO Pins: The board provides numerous General Purpose Input/Output (GPIO) pins which can be used for various digital input/output functionalities. These pins also support functionalities like PWM, I2C, SPI, and more.
  2. Analog Inputs: Several pins on the ESP32 DevKit V1 are capable of reading analog signals, making them suitable for interfacing with analog sensors.
  3. 3.3V and GND Pins: These are used to power external components or sensors.
  4. 5V and GND: The board can also provide a 5V output, which is useful for powering external modules that require more power.
  5. VIN: This is the input voltage pin, which can be used to power the board when not using the USB connection.
  6. EN: This is the enable pin. It’s used to reset the microcontroller.
  7. TX/RX: These pins are used for serial communication.
  8. SPI Interface: The board has pins for SPI communication, enabling fast data transfer with peripherals like displays or flash memory.
  9. I2C Interface: The ESP32 DevKit V1 supports I2C communication, which is widely used for interfacing with sensors and other peripherals.
  10. Touch Sensor Pins: Some GPIOs can be used as capacitive touch inputs, offering an interface for touch-based input devices.
  11. VP/VN: These are the pins for the internal hall effect sensor.
  12. USB-to-UART Bridge: This feature is crucial for programming the ESP32 using a USB cable and also for serial communication with a computer or other USB host devices.

This board’s flexibility with various protocols and interfaces makes it ideal for a wide range of IoT and embedded system applications.
